Product DescriptionCompany Info.<>
- Processing customization:
- Yes
- Sewage treatment capacity:
- 0.5-300 m3/h
- Model:
- ZTMBR
- Air volume:
- 30 customization m3/min
- Ozone consumption:
- 25 customization g/h
- Equipment height:
- 2500 customization m
1. fundamental
MBR is a new sewage treatment device which combines ultrafiltration and microfiltration membrane separation technology with bioreactor in sewage treatment. This reactor combines the advantages of membrane and biological treatment technologies. Activatedsludge in MBR and microbial community on activated sludge adsorb and decompose soluble organic pollutants in wastewater to purify wastewater. Ultrafiltration membrane and microfiltration membrane can replace secondary sedimentation tank completely as sludge separation unit. Ultrafiltration membrane and microfiltration membrane intercept microbial floc and organic matter with larger molecular weight in activated sludge mixed solution and make them stay in reactor, so as to obtain high biological concentration in reactor and prolong the residence time of organic solids, thus greatly improving the oxidation rate of microorganisms to organic matter.
2. MBR Features
2.1 Good quality of effluent water
Due to the membrane separation technology, there is no need to set up other solid-liquid separation equipment such as filtration. Efficient solid-liquid separation separates suspended substances, colloidal substances and microbial flora lost from biological units in wastewater from purified water, and can be directly reused without tertiary treatment, with high water quality safety. nbsp;
2.2 Small footprint
The high concentration of microorganisms in the biological treatment unit of membrane bioreactor greatly improves the volume load, and the high efficiency of membrane separation greatly shortens the hydraulic retention time of the treatment unit and reduces the occupied area. At the same time, the membrane bioreactor uses membrane modules, does not need a sedimentation tank and a special filtration workshop, and the system occupies only 60% of the traditional method. nbsp;
2.3 Low operating costs
Due to theefficient oxygen utilization efficiency of MBR and the unique intermittent operation mode, the operation time and electricity consumption of aeration equipment are greatly reduced, saving power consumption. At the same time, because the membrane can filter harmful substances such as bacteria and viruses, it can significantly save the long-term operation cost caused by chemical disinfection, and the membrane bioreactor process does not need to add flocculants to reduce the operation cost. nbsp;
3. MBR classification
Membrane bioreactor is composed of membrane module and bioreactor. The classification of membrane bioreactor is determined by the combination mode and respective properties of the two parts. Due to the different properties of membrane modules, MBRcan be divided into internal pressure type and external pressure type. The water permeation direction of internal pressure type is from the inside of membrane to the outside, while that of external pressure type is just opposite. However, in practice, the external pressureMBRis still relatively common, because the internal pressureMBRis easy to plug, resulting in a reduction in membrane flux, thus reducingthe treatment effect of the MBR. According to the combination of membrane module and bioreactor. MBR can be dividedinto two types: integrated and separate. The integralMBRis to immerse the membrane module directly in the bioreactor, and the activated sludge aerobically degrades organic pollutants in the aeration tank. Due to the turbulence generated on the membrane surface due to the agitation of the air, colloidal particles are forced to leave the membrane surface to slow down the clogging of the membrane. Water is discharged through the suction of the suction pump. SeparatedMBRmeans that the membrane module and bioreactor are placed separately, and the pollutants in the water are first removed by activated sludge in the bioreactor, and the treated wastewater is beaten into the membrane module by a high pressure pump, so as to achieve the purpose of sludge separation. According to the different roles of membrane modules in bioreactors, they can be divided into three categories: MBR for solid separation and retention, oxygen mass transfer membrane bioreactor (MABR) for bubble-free aeration in the reactor, and extraction membrane bioreactor (EMBR) for extracting priority pollutants from industrial wastewater. nbsp;- Name（chinese）
